Tyz-130 Autotic Carton Machine

Short Description:


Product Detail

FAQ

Product Tags

TYZ-130 Autotic Carton MachineTyz-130 Autotic Carton Machine

Tyz-130 Autotic Carton Machine

Main performance and structural characteristics:
1. It adopts automatic feeding, unpacking, feeding, sealing and output. And other packaging forms, the structure is compact and reasonable, and the operation and adjustment are simple;
2. Servo / stepping motor, touch screen and PLC programmable control system are adopted to make the display operation of the man-machine interface clearer and more convenient, with high degree of automation and more humane;
3. The photoelectric eye automatic detection and tracking system is adopted, and there is no product without suction box, which saves the packaging materials to the maximum;
4. Large range of packaging, easy adjustment, fast conversion between various specifications and sizes;
5. It is not necessary to change the mold to change the specifications, only adjustment is needed;
6. When there is no product or the product is not in place, the machine will idle without pushing the product. When the product is restored to supply, it will automatically run. When the product is in the box, it will automatically stop and the main drive motor overload protection device.
7. Automatic display of packing speed and counting:
8. According to customer requirements, a flip-up safety cover is adopted for easy operation and beautiful appearance.
9, can be linked with aluminum-plastic packaging machine, pillow packaging machine, three-dimensional packaging machine, bottling line, filling machine, labeling machine, inkjet printer, online weighing instrument, other production lines and other equipment to achieve linked production;
10. Can design various automatic feeders and cartoning systems according to the requirements of packaging materials;
11. According to customer requirements, the hot melt adhesive machine can be equipped with hot melt adhesive spray glue sealing box.

Technical parameter:

Item Parameter Note
Material type
Cartoning speed 30-100 Box/minute
Paper box requirement Paper quality 250-400g/m2 Requires flat surface and can be absorbed
Size range L(50-250) x W(25X150) x K(15-70)  (LxWxH)
Compressed air Pressure ≥0.6MPa
Air consumption 20m3/h
Power 220V-380V   50Hz
Main motor 1.5kw
Overall dimension LXWXH 3500X1500X1800mm Machine dimension
Net weight 1300kg

Machine details:
Tyz-130 Autotic Carton Machine

Tyz-130 Autotic Carton Machine

Samples:
Tyz-130 Autotic Carton Machine

Factory tour:
Tyz-130 Autotic Carton Machine

RFQ:

Q: Do you provide OEM service and do you proivde after sales service?
We provided OEM service and yes, we provide oversea after-sale service.



Q:Can you send me the video to show the machine works?
A:Certainly, we will show you the video refer to your products.



Q:How can I know your machine is designed for my product
A: Send your samles to us, also test your samples on my machine.

Q: Can we visit your factory? and where is your factory?
You are welcome to see our production scale, My factory is located in Ruian city, Zhejiang province.

Q: What if there are some complicate problems about machine after buying them?
Contact with us by email or telephone, even we can go to visit you with our technician if it necessary.

Q: What’s your advantage about your products?
18 year expereience in this field, good machine stability with favorable price requirements.
